Industrial Linear Flame Treater for Flat Parts
Machine Type: Linear Flame Treating conveyor for flat parts
Manufacturer: Deco Tech
Origin: Made in China with world-class components
Deco Tech’s linear flame-treatment systems provide consistent and repeatable surface activation for flat plastic parts and other substrates. Designed for printing, coating, and adhesive bonding applications, these systems increase surface energy for superior adhesion and long-term performance.
HIGH-PERFORMANCE LINEAR FLAME TREATER FOR FLAT PARTS
Our flame treaters deliver uniform surface activation across a 300 mm (11.81") standard treatment width, with custom wider formats available for larger parts. Dual flame assemblies and a fully guarded design ensure safe, stable, and efficient operation in demanding industrial settings.
KEY FEATURES
- Uniform & Consistent Treatment: Dual flame burners provide even coverage for stable surface-energy levels across the entire part width.
- Industrial Stainless-Steel Construction: Built for continuous-duty operation with a durable, corrosion-resistant stainless-steel frame and conveyor system.
- Operator Safety & Protection: Fully enclosed flame section and safety guards help prevent contact with the flame and moving components.
- Integrated Exhaust System: Includes a high-efficiency exhaust fan; simply connect your facility’s vent piping.
- High Throughput Capability: Handles hundreds to thousands of flat parts per hour depending on part size, conveyor speed, and model selection.
IDEAL APPLICATIONS
- Pad printing, screen printing, and digital inkjet pre-treatment.
- Increasing adhesion for inks, paints, coatings, and adhesives.
- Flat plastic parts, molded components, packaging items, and industrial components.
- Pre-paint and pre-coating processes.
High-volume manufacturing lines requiring consistent adhesion performance.
SPECIFICATIONS
| Technical Data | DT-220-F | DT-3030-F |
|---|---|---|
| Maximum Speed: | Conveyor speed up to 15 meters/minute | Conveyor speed up to 15 meters/minute |
| Product Width: | up to 100mm (3.94") | up to 300mm (11.81”) * |
| Voltage: | 220V 50/60Hz 120W | 220V 50/60Hz 120W |
| Air Requirement: | 4-6 bar | 4-6 bar |
| Fuel: | LPG or Natural gas (customer to specify) | LPG or Natural gas (customer to specify) |
| Machine Size: (LxWxH): | 2,200 x 600 x 1,800mm (86.6” x 23.6” x 70.8”) | 3,000 x 780 x 1,690mm (118" x 30.7" x 66.5") |
| Crated Size (LxWxH): | 2,460 x 690 x 2,000mm (96.8” x 27.16” x 78.7”) | TBA |
| Machine Weight: | 220 kg (484 lbs.) | 300 kg (661 lbs.) |
| Crated Weight: | 320 kg (704 lbs.) | TBA |
*Custom widths are available upon request.
WHY FLAME TREATMENT IMPROVES ADHESION
Flame treatment increases surface energy on low-tension materials such as PE, PP, ABS, and many engineered plastics. This allows inks, paints, coatings, and adhesives to wet out properly and form a strong bond, dramatically reducing defects such as ink lifting, coating failure, and peeling.
Manufacturers use flame treatment to ensure reliable, long-lasting adhesion in industrial decorating and finishing processes — making it a critical step for quality control.
REQUEST A QUOTE OR CUSTOM CONFIGURATION
Deco Tech can configure the system to match your part size, line speed, and production requirements. Standard and fully custom flame-treatment systems are available.
